- ‘A’ shaped structured column with multiple cross ribs offers high cutting performance.
- Wide base offers very higher stability for big size jobs during heavy duty machining.
- LM Roller Guideways for all 3 axes provides higher cutting dynamics and longer machine life.
- Imported spindles from Taiwan with G1 balanced grade offers superior finish up to 0.45Ra Value.
- Controller options with latest configuration from Mitsubishi and Fanuc available.
- High efficiency and productivity can be ensured with Fred rate of 10,000mm/min and rapid feed rate of 36 m/min.
Model | VL 850 |
---|---|
Travel | |
X / Y / Z travel | 850/510/510mm |
XYZ ballscrews | C3 40mm |
Spindle nose to table surface | 140 ~ 650mm |
Spindle center to column surface | 560mm |
Table | |
Table size | 1,000 * 500mm |
T slot ( Size / Qty / Dist. ) | 18mm x 5 x 100mm |
Max. table load | 800kg |
Spindle | |
Speed | 8,000rpm (Opt:10,000rpm) |
Taper | BBT40 |
Transmission | Belt Type |
Guide ways type | LM Roller |
Feed Rate | |
Rapid feed rate of X,Y,Z Axis | 36 / 36 / 36 m / min |
Cutting feed rate | 1-10000mm / min |
Accuracy asper VDI – DGQ – 3441 | |
Position accuracy | ±0.005 |
Repeatability | ±0.003 |
Automatic Tool Changer | |
Tool storage capacity | Arm 24T ATC |
Max. tool diameter(Arm Type) | Full: 80mm Next empty : 150mm |
Max. tool length ( Arm Type) | 300 mm |
Max. tool Weight ( Arm Type ) | 8kg |
CNC Controller & Motor | |
CNC controller | Mitsubishi M80 |
Spindle motor | 7.5/11 ( Opt: 7.5/11/15 )kW |
Axis motor X,Y,Z | 2.0/2.0/3.0 kW |
Coolant | |
Pressure | 10kg/cm² |
Coolant pump | 0.75HP |
Coolant tank capacity | 230L |
Air & Power Supply | |
Air source | 5-7kg/cm² |
Power supply | 20kVA |
Machine Size | |
Machine dimensions (L*W*H) | 2,700 x 2,250 x 2,750mm |
Machine net weight (approx) | 5,500Kg |
- Full Guarding
- Rigid Tapping
- Coolant Pump
- Transformer
- Handwheel
- Panel AC
- Auto Lubrication
- Halogen Work Light
- Signal Lamp
- Coolant Gun
- Air Gun
- Head Coolant
- Cutting Air
- Spindle Air Blast
- Tools Box
- Manuals
- USB/RJ45/RS232 Interface
- ECB
- Fanuc Oi-MF/Siemens 828D SL
- Spindle Chiller
- 20 Bar Coolant Through Spindle
- 16/20T Armless ATC
- 200mm Raiser Block (on select models)
- TPM
- 20/24T Arm Type ATC
- Flush Coolant
- Scrapper Type Chip Conveyor
- Screw Type Chip Conveyor
- Dual Type Chip Conveyor
- Automatic Grease Lubrication
- Oil Skimmer
- 4th Axis Cable Preparation
- 4th Axis Rotary Table
- Automatic Tool & Workpiece Measurement
- CE Safety
