S&T Machinery High Performance CNC Double Column Machining Center DL3119

DL3119

Table(LxW)(mm)

3000x1500

Travel(XxYxZ)(mm)

3100x1900x900

Spindle

BT 50 - 6000 / ZF Germany

15/18.5 (18.5/22 Opt.)

Gear Box Equipped with a ZF gear box with a gear ratio of 1:4 in all models to provide high torque and support heavy cutting.
Base Lubricant recycling keeps the base clean.
Lubricant and coolant separation prolongs the service life of the coolant.
A complete chip management system avoids damage to the guideway.
Linear Guideway The X axis is equipped with R55 roller type linear guideways, offering high rigidity and precision for a long service life and highly accurate motion.
Distance Between Columns Ranges from 1400mm to 3000mm to meet different customers' machining requirements.
High Speed, Fast & Precise This series is built for efficiency, featuring both high speed and accuracy with a linear guideway design that ensures a long service life and high accuracy.
It is the perfect solution for efficient machining and heavy cutting.
